Aeoon-Kyo Hybrid

AHYBRID
Login for pricing

    Kyo Hybrid Series

    The first true fusion of screen printing and DTG textile printing—designed for high-volume runs, complex fabrics, and maximum production flexibility while slashing white-ink usage.

    • Switch between screen, DTG or hybrid modes seamlessly
    • Print on pretreated or untreated fabrics with 600–2400 dpi clarity
    • One-step KyoToScreen workflow for effortless setup and precise registration

    Key Features

    🎨
    Screen printing & digital printing simultaneously
    🔄
    KTS – KyoToScreen workflow
    📱
    Tablet app for screen setup
    🔬
    Screen adjustment to 0.001 mm
    💾
    Save & recall settings via our app
    🖨️
    Print resolution 600–2400 dpi
    🔗
    Integrated API interface
    💦
    Print with or without pretreatment
    👕
    Handles complex fabrics
    📶
    Independent printing stations
    💡
    Low white consumption for cost savings
    Sample Prints
    Hybrid – Neon Color
    Hybrid Close-Up

    See It In Action

    Industrial printheads: 8 or 12 Kyocera KJ4B – 2656 nozzles per head
    Print stations: 3
    Screenprint Unit: Integrated
    KTS Pallet: 1
    Intermediate Dryer: High-performance NIR dryer
    Max. Print size: Framed (3 stations): 40×50 cm (~16×20 in)
    Frameless (3 stations): 60×90 cm (~24×35 in)
    Frameless (1 station): 200×98 cm (~79×39 in)
    Max. Screenprint size: Framed (3 stations): 40×50 cm (~16×20 in)
    Printable material: Cotton, synthetics, mixed fibers, canvas, leather & more
    Print resolution: 600 dpi up to 2400 dpi
    Operating system: Linux OS
    RIP Software: aeoon RIP Software
    Interface: OPC-UA & REST
    Color channels: CMYK + KYMC, CMYK + 4 White (8 heads)
    CMYK + KYMC + 4 White, CMYK + 8 White (12 heads)
    Ink type: Water-based pigment ink
    Crash prevention: Integrated
    Environmental conditions: Temp 22–24 °C;
    Humidity 50–80 % (non-condensing)
    Machine size: 410 × 350 × 200 cm (~161 × 138 × 79 in)
    Machine weight: 2600 kg / 5732 lb
    Electrical connections: 3 × 400/208 V + N + PE, 50/60 Hz, max power 8.5 kVA
    Compressed air: 7 bar – Quality Class 5 (oil ≤ 25 mg/m³, dust ≤ 40 μm/10 mg/m³, water ≤ 7 DTP/7.8 g/m³);
    max 500 L/min
    HYBRID Series KTS Pallet

    Easy Screen Preparation with KTS Pallet

    KyoToScreen – Print directly on the screen!

    • No film needed
    • Saves space: only a small darkroom & dryer required
    Download Hybrid Brochure
